Datapath ImageDP4+ Wall Control 2GB
Datapath ImageDP4+ Wall Control 2GB
Warranty:
1 Year - DataPath
Interface:
PCIe 2.1 x16
Dimensions:
110mm x 177mm, including the heat sink
Memory Capacity:
2GB
Max. Resolution:
4x 2560 x 1600 at 60 Hz or 2x 3840 x 2160 @ 30Hz
Max Color Depth:
8-bit per component
Display Output:
4x Display Port 1.1
Power Rating (TDP):
15 watts
Designed for professional video projects, the ImageDP4+ graphics card is a highly scalable graphics card for use with multiple screen or projector installations.

The ImageDP4+ cards operate under Windows®10, driving the very latest in graphical performance. Multiple cards and outputs work together to spread the Windows desktop across a multi-screen surface. The Datapath drivers can allow for monitors positioned in either landscape or portrait or a mixture of the two. The ImageDP4+ is optimised for use with the Datapath Vision range of capture cards and IP decoding cards for systems requiring SD, HD, 4K and IP video capture and display. Video windows can be positioned and sized anywhere on the multi-screen desktop, while maintaining full frame rate and true colour rendering throughout. When used with Datapath Vision capture cards HDCP content can be delivered to the screens.


  1. Each of the 4 DisplayPort outputs can support up to 2560 x 1600 @ 60fps, or use 2 outputs to support up to resolutions of 3840 x 2160 @ 30Hz.
  2. The ImageDP4+ includes 2GB of memory that will drive the most demanding of applications.
  3. Datapath’s ImageDP4+ card natively supports four full-sized DisplayPort outputs which allow for locking cable connectors and significantly longer cable
Price: $1,330.00
