Supermicro F619P2-RTN + X11DPFR-SN 8-Node 4U
Supermicro F619P2-RTN + X11DPFR-SN 8-Node 4U
Warranty:
3 Years - Supermicro
Dimensions (HxWxD):
6.96" x 17.63" x 29"
Weight:
150 lbs (net), 200 (gross)
Motherboard:
Super X11DPFR-SN (included)
CPU Support:
Xeon Scalable (70-165W TDP)
Graphics:
Aspeed AST2500 BMC
Memory Slots:
12 Per Node
Memory Capacity:
Up to 1.5TB ECC 3DS LRDIMM/RDIMM Per Node
SATA Support:
14x SATA3 Per Node
M.2 Support:
1x M.2
Expansion Slots:
1x PCIe 3.0 x16 (Low-profile), 1x PCIe 3.0 x16 (SIOM)
External Bay:
6x 2.5" SATA3 or 2x 2.5" SATA3 + 4x NVMe U.2
LAN:
Flexible networking via SIOM,1x IPMI
USB:
2x USB 3.0
Power Supply:
2200W Redundant Power Supplies with PMBus
Price: $10,300.00
