Supermicro 2-Xeon 6029UZ-TR4+ 12-Drive 2U
Supermicro 2-Xeon 6029UZ-TR4+ 12-Drive 2U
Warranty:
3 Years - Supermicro
Dimensions HxWxD:
3.5" x 17.2" x 28.46"
Weight:
36 lbs (net), 72 lbs (gross)
Motherboard:
Supermicro X11DPU-Z+
CPU Support:
Dual Xeon Scalable, 70-205W TDP
Memory Slots:
24
Memory Speed:
Up to 2666 MHz
Memory Capacity:
Up to 3TB ECC 3DS LRDIMM/RDIMM
Graphics:
1x VGA, ASPEED AST2500
Drive Support:
12x 3.5" HS
Expansion:
1x PCIe 3.0 x16 (FH), 5x PCIe 3.0 x8 (FH), 1x PCIe 3.0 x8 (LP), 1x PCIe 3.0 x8 (internal LP)
LAN Support:
4x 1GbE (I350-AM4 AOC), 1x IPMI
Power Supply:
1600W Redundant Titanium Level (96%)
USB:
3x USB 3.0 (2 rear, 1 Type A)
Serial Port:
1x Header
Cooling:
4x 80mm
Due to the complexity of integration, this product is sold as a completely assembled system only (with minimum 2 CPUs and 4 DIMMs).
Price: $2,350.00
