Supermicro 5039MA16-H12RFT + A2SD1-3955F 12-Node Atom C3955 3U
Supermicro 5039MA16-H12RFT + A2SD1-3955F 12-Node Atom C3955 3U
Warranty:
1 Year - Supermicro
Dimensions (HxWxD):
5.21" x 17.5" x 29.5"
Weight:
95lbs (net), 125lbs (gross)
Motherboard:
2x A2SD1-3955F
Processor:
Atom C3955 2.1GHz (Turbo 2.4GHz) 16-Core, 32W TDP Per Node
Graphics:
AST2400 BMC
Memory Slots:
4x 288pin per node
Memory Type:
VLP DDR4, ECC REG or ECC Unbuffered per node
Memory Capacity:
Up to 128GB RDIMM, 64GB UDIMM per node
SATA Support:
4x SATA3 per node
M.2 Support:
2x NVMe per node
Internal Bays:
2x 3.5" or 4x 2.5" per node
Expansion:
Supermicro AOC only per node
Network:
2x 10GbE via C3000 SoC per node
Power Supply:
2000W Titanium Redundant
Cooling Fans:
4x 90mm
Price: $12,000.00
